2.56kwh 5.12kwh 10.24kwh 200a Lithium Batterie Lifepo4 Lithium Battery For Solar Power Storage
ESS Lithium Battery Description
The Stackable Home Energy Storage System Series can be wall-mounted and stackedat the same time, Flexible Assembly, Space-saving, Plug-and Play, Safety & Security, Use advanced & enhanced security features double safety protection design, Remote monitoring: You can monitor the batteryany where by computer software
ESS Lithium Battery Features
High Energy Density: Having excellent energy density means that it can store more power under the same volume and weight to meet long time and high intensity power demand. Features
Long cycle life: After careful design and optimization, this product has a charge/discharge cycle life of up to thousands of times, which greatly reduces the frequency of battery replacement and maintenance costs.
Fast charging: Supporting fast charging technology, the battery can be fully charged in a short time, which greatly improves the usage efficiency.
Safe and stable: Built-in multiple safety protection measures, including overcharging, over-discharging, overheating, short-circuit and other protection mechanisms, to ensure the safety of the use process.
Environmental protection and energy saving: Made of environmentally friendly materials, it is pollution-free, while the high efficiency of energy utilization also helps to reduce energy waste, in line with the concept of green development.
ESS Lithium Battery Specification
| Model | 1 Module | 2 Modules | 3 Modules | 4 Modules | 5 Modules | 6 Modules |
| Nominal capacity(kwh) | 5.12 | 10.24 | 15.36 | 20.48 | 25.6 | 30.72 |
| Operating voltage | 48V |
| Weight (Kg) | 96.5 | 151.5 | 206.5 | 261.5 | 316.5 | 371.5 |
| Nominal voltage | 48V |
| Dimension (mm) | 600x460x457 | 600x460x637 | 600x460x817 | 600x460x997 | 600x460x1177 | 600x460x1357 |
| Battery cell type | LiFePO4 |
| Communication method | CAN/RS485/RS232 |
| Operating temperature range | Charging: 0~45℃ Discharging: -10~50℃ |
| Protection level | IP55 |
| Installation method | Floor installation |
| Cycle life | >6000 Cycles(80%DOD) |
| Peak charge/discharge current (@25℃ ,5S) | 100A |
| Self-discharge rate | ≤3.5%/month/@25°C |
| Parallel function | 1S~6S |
ESS Lithium Battery Connection Diagram
FAQ
1. Is the battery used in the battery pack grade A?
Yes, we only use Grade A and Brand new cells inside.
2.Do you test and match the battery before installing the battery pack?
Yes, every cell will be tested capacity, IR, voltage to surely match
Voltage:The deviation less than 0.01V
Resistance:The deviation less than 0.1mΩ
Capacity: Same capacity matched
3.How do I store my batteries?
When the product is not in use for a long time, it should be stored in a dry, clean and well-ventilated warehouse at 10°C～35°C, avoiding inflammable and explosive materials; the battery pack should be charged and maintained regularly every three months to ensure that the battery best performance state.
4.What is the cycle life of the battery?
6000 cycle life @ 80% DOD
5.What's the warranty of your 48V/51.2V battery pack?
5 years warranty, if there is broken item under quality problem within warranty time, we will offer free replacements or refund, up to your needs
6.Do your batteries support series or parallel connection?
Our 48V battery packs support up to 15pcs in parallel, if you need series connection, please contact our sales staff
