Custom-Made 24V 25.6V 100ah Deep Cycle Lithium Battery For Solar UPS ESS Lithium Battery
ESS Lithium Battery Features
1. Your can read the battery data throughcomputer, bluetooth, mobile phone.
2. You can read the battery data on computer: single cell voltage, capacity, temperature,cycles, etc.
3. You can read battery data on cell phone: include single cell voltage, capacity, current, battery pack total voltage, total capacity, temperature, cycles, etc.
ESS Lithium Battery Functions
1. Over charge protection(to prevant batteryovercharging)
2. Over current protection(to prevant batteryover current)
3. Short circuit protection(Automatically Cut offand Recovery)
4. Over discharge protection(to prevant batteryover discharging)
5. Over temperature protection(to prevant a high temp.and ensure a safe life)
6. Cell balancing function(to balance the single cellvoltage and ensure a longcycle life)
Lithium Battery Replacement Lead-Acid Specification
| Model | 25.6V50Ah | 25.6V100Ah | 25.6V120Ah |
| Nominal Voltage | 25.6V |
| Nominal Capacity @25C | 50AH | 100AH | 120AH |
| Nominal Energy @25°C | 1280WH | 2560WH | 3072WH |
| Battery Cell Type | Prismatic 50Ah | Prismatic 100Ah | Prismatic 120Ah |
| Configuration(xSxP) | 8S1P | 8S2P | 8S2P |
| Max.Continous Charge Current @25°C | 7A | 12A | 50A |
| Max. Continous Discharge Current @25°C | 7A | 12A | 50A |
| DC Resistance | ≤10mΩ |
| Full Charged Voltage | 29.2V |
| Discharge Cut-off Voltage | 20V |
| Operate Temperature Range | Charge: 0°C~55°C; Discharge: -20°C~60°C; Storage: -20°C~45°C |
| Dimension (mm) | 326x171x215mm | 522x240x218mm | 522x240x218mm |
| Weight(KG) | 12.5KG | 25KG | 28KG |
| Teminal Type | F1 terminal | Screw teminal |
| Cover Sealing type | Screw / gel sealing optional |
| Waterproof | IP65 |
| Cyde life | 100% DOD Cycles @ 25xC 1C/1C: >2000 times80% DOD Cycles @ 25C 1C/1C: >6000 times50% DoD Cycles @ 25C, 1C/1C: >5000 times |
| LCD Screen Display | Optional(Show voltage V,Power %) |
| Bluetooth | Optional (Bluetooth with mobile APP) |
| Series and Parallels Function | Available to make in series and parallels to get 24V, 36V, 48V |
| Heating Function | Optional, Suitable for cold area application |
Our Advantages
Professional Technical Team, Xwell's R&D technical team has recievedmore than 20 invention and applicationpatents.
Professional Sales Team, xwell poccesses well-trained sales team which helps customers addressing difficulty meeting in battery or battery solution selecting.
Unique Pack Technique, xwell possesses special pack techinique to better protect the battery and increase the life span of the battery pack.
Puntual Delivery, xwell has strict production plan to promise on time delivery.
Safety Certification Gurantee, Most products have been certified according to international standard including CE,MSDS,UN38.3.etc.
Perfect after Sales-service, xwell has a professional QC team which applies strict quality controlon production and provide perfect after-sale service to customers
