Manufacturer Supply Lithium LiFePO4 Battery 12V 7Ah 12ah 50ah 100ah 200ah For Small UPS System Ess With Smart BMS
ESS Lithium Battery Features
Waterproof protection: The top cover and bottom shell aremolded by injection molding and the terminal is fixed with glue, effectively prevent rain damage to the battery because of good sealing
Portable hand-held: Humanized portable design, comfortable and portable, so that you can set sail on your journey at any time.
LED Battery Display: You can read the battery voltage and capacity from the LED screen.(it's optional function)
Terminals: M8 pure copper terminals can supporthigh current,good conductivity, rustand corrosion resistance.
ESS Lithium Battery Applications
1. Lithium Battery for Electric Cars/Motorcycle
2. Lithium Battery for RV/ Camping
3. Lithium Battery for Boats /Yacht/ Marine
4. Lithium Battery for Solar energy storage system
5. Lithium Battery for Medical Devices
6. Lithium Battery for Robots
Lithium Battery Replacement Lead-Acid Specification
| Model | 12.8V7Ah | 12.8V12Ah | 12.8V50Ah | 12.8V100Ah | 12.8V200Ah |
| Nominal Voltage | 12.8V |
| Nominal Capacity @25C | 7AH | 12AH | 50AH | 100AH | 200AH |
| Nominal Energy @25°C | 89.6WH | 153.6WH | 640WH | 1280WH | 2560WH |
| Battery Cell Type | Cylinder | Prismatic 50Ah | Prismatic 100Ah | Prismatic 100Ah |
| Configuration (xSxP) | 4S1P | 4S2P | 4S1P | 4S1P | 4S2P |
| Max. Continuous Charge Current @25°C | 7A | 12A | 50A | 100A | 100A |
| Max. Continuous Discharge Current @25°C | 7A | 12A | 50A | 100A | 100A |
| DC Resistance | ≤10mΩ |
| Full Charged Voltage | 14.6V |
| Discharge Cut-off Voltage | 10V |
| Operate Temperature Range | Charge: 0°C~55°C; Discharge: -20°C~60°C; Storage: -20°C~45°C |
| Dimension (mm) | 152x65x94mm | 152x99.5x100mm | 229x138x208mm | 326x171x215mm | 522x240x218mm |
| Weight (KG) | 1.1KG | 1.7KG | 7KG | 12.5KG | 25KG |
| Terminal Type | F1 terminal | Screw terminal |
| Cover Sealing type | Screw / gel sealing optional |
| Waterproof | IP65 |
| Cycle life | 100% DOD Cycles @ 25xC 1C/1C: >2000 times80% DOD Cycles @ 25C 1C/1C: >6000 times50% DoD Cycles @ 25C, 1C/1C: >5000 times |
| LCD Screen Display | Optional (Show voltage V, Power %) |
| Bluetooth | Optional (Bluetooth with mobile APP) |
| Series and Parallels Function | Available to make in series and parallels to get 24V, 36V, 48V |
| Heating Function | Optional, Suitable for cold area application |
Our Advantages
Professional Technical Team, Xwell's R&D technical team has recievedmore than 20 invention and applicationpatents.
Professional Sales Team, xwell poccesses well-trained sales team which helps customers addressing difficulty meeting in battery or battery solution selecting.
Unique Pack Technique, xwell possesses special pack techinique to better protect the battery and increase the life span of the battery pack.
Puntual Delivery, xwell has strict production plan to promise on time delivery.
Safety Certification Gurantee, Most products have been certified according to international standard including CE,MSDS,UN38.3.etc.
Perfect after Sales-service, xwell has a professional QC team which applies strict quality controlon production and provide perfect after-sale service to customers
