Home Lithium Batteries Stackable Battery LiFePO4 Stack Battery Wall

Brand Name : XWELL

Model Number : XW-5120W-1

Certification : UN38.3,MSDS,UL,CB,BIS,PSE,GB4943.1 safety standard, CE, FCC, ROHS, battery UN38.3, MSDS, UL, CB, BIS, PSE

Place of Origin : China

MOQ : 1 pcs

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 5000 pcs per month

Delivery Time : 7-10 working days

Packaging Details : Carton

Production Capacity : 5000PCS/Month

Pack capacity : 50Ah 100Ah 200Ah

Pack energy : 2.56Kwh 5.12Kwh 10.24Kwh (Optional)

Discharge current : 50A

Max charge current : 50A

Discharge cut-off voltage : 42.5V

Display : LCD optional

Communication interface : RS485, RS232, CAN

Cycle life : >6000 Cycles(80%DOD)

Contact Now

Home Lithium Batteries Stackable Battery LiFePO4 Stack Battery Wall

Coverage of application

  • > Safe & reliable performance with Lithium Iron Phosphate (LFP) cell

    > Flexible investment with 5kWh modular design, scalable from 5kWh to 80kWh

    > Multiple protection function to ensure service life up to 10 year

    > More usable energy with pack level energy optimization

    > Compatible with both single & three phase off grid/hybrid inverter

    > Faulty battery module auto isolates to keep system operating

    ● Modular designer, natural cooling, indoor use

    ● Compact size and easy installation

Rackmount Lithium Battery Specification

Model 51.2V50Ah 51.2V100Ah 51.2V200Ah
Nominal voltage 51.2V
Nominal capacity (kwh) 2.56 5.12 10.24
Cell type LiFePO4
Standard charge voltage 54.6V(adjustable)
Max charge current 50A
Discharge cut-off voltage 42.5V(adjustable)
Max discharge current 50A
Display LCD(Optional)
Communication interface CAN/RS485/RS232
Cycle life >6000 Cycles (80%DOD)
Charge temperature range 0~45°C
Discharge temperature range -20~60°C
Color Black
Dimension (mm) 442x410x133
3U		 442x410x177
4U		 550x442x220
5U
Weight About 35Kg About 42Kg About 84Kg
Installation method Rack Mount

Cell Specification of Rackmount Lithium Battery

Home Lithium Batteries Stackable Battery LiFePO4 Stack Battery Wall

Operation Pannel of Rackmount Lithium Battery

Home Lithium Batteries Stackable Battery LiFePO4 Stack Battery Wall

Size of Rackmount Lithium Battery

Home Lithium Batteries Stackable Battery LiFePO4 Stack Battery Wall

Structure of Rackmount Lithium Battery

Home Lithium Batteries Stackable Battery LiFePO4 Stack Battery Wall

Application of Rackmount Lithium Battery

Home Lithium Batteries Stackable Battery LiFePO4 Stack Battery Wall

What We Offer?

Supply chain solution, strict quality control, real-time response
OEM/ODM Manufacturer, custom sizes and shapes available on request
Suggestion of new design or material, new technology and cost structure
Engineers team at your service
Flexible small orders are acceptable
One-stop supply to eliminating messy links
