5Kw 10Kw 15Kw 48V 100Ah 200Ah 260Ah Lithium Rack Mounted Battery

Product Categories
GUANGDONG XWELL TECHNOLOGY CO., LTD.
Contact Now

5Kw 10Kw 15Kw 48V 100Ah 200Ah 260Ah Lithium Rack Mounted Battery

Brand Name : XWELL

Model Number : XW-5120W-1

Certification : UN38.3,MSDS,UL,CB,BIS,PSE,GB4943.1 safety standard, CE, FCC, ROHS, battery UN38.3, MSDS, UL, CB, BIS, PSE

Place of Origin : China

MOQ : 1 pcs

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000 pcs per month

Delivery Time : 7-10 working days

Packaging Details : Carton

Battery Type : Lithium Ion

Output Power Range : 10~20 kWh

Pack capacity : 50Ah 100Ah 200Ah

Pack energy : 2.56Kwh 5.12Kwh 10.24Kwh (Optional)

Discharge current : 50A

Max charge current : 50A

Discharge cut-off voltage : 42.5V

Display : LCD optional

Communication interface : RS485, RS232, CAN

Cycle life : >6000 Cycles(80%DOD)

Contact Now

5Kw 10Kw 15Kw 48V 100Ah 200Ah 260Ah Lithium Rack Mounted Battery

Inverter: Converts the DC electricity stored in the storage batteries into alternating current (AC) electricity for use. The inverter converts the DC electricity stored in the storage batteries into AC electricity, which is supplied to household appliances.

Storage batteries: Store the electricity generated by the solar panels. During the day, the storage batteries can store excess electricity generated by the solar panels for use at night or during cloudy weather. When electricity is needed, the storage batteries release the stored ener


Rackmount Lithium Battery Specification

Model51.2V50Ah51.2V100Ah51.2V200Ah
Nominal voltage51.2V
Nominal capacity (kwh)2.565.1210.24
Cell typeLiFePO4
Standard charge voltage54.6V(adjustable)
Max charge current50A
Discharge cut-off voltage42.5V(adjustable)
Max discharge current50A
DisplayLCD(Optional)
Communication interfaceCAN/RS485/RS232
Cycle life>6000 Cycles (80%DOD)
Charge temperature range0~45°C
Discharge temperature range-20~60°C
ColorBlack
Dimension (mm)442x410x133
3U		442x410x177
4U		550x442x220
5U
WeightAbout 35KgAbout 42KgAbout 84Kg
Installation methodRack Mount


Cell Specification of Rackmount Lithium Battery

5Kw 10Kw 15Kw 48V 100Ah 200Ah 260Ah Lithium Rack Mounted Battery

Operation Pannel of Rackmount Lithium Battery

5Kw 10Kw 15Kw 48V 100Ah 200Ah 260Ah Lithium Rack Mounted Battery
Size of Rackmount Lithium Battery

5Kw 10Kw 15Kw 48V 100Ah 200Ah 260Ah Lithium Rack Mounted Battery

Structure of Rackmount Lithium Battery

5Kw 10Kw 15Kw 48V 100Ah 200Ah 260Ah Lithium Rack Mounted Battery

Application of Rackmount Lithium Battery

5Kw 10Kw 15Kw 48V 100Ah 200Ah 260Ah Lithium Rack Mounted Battery
What We Offer?

Supply chain solution, strict quality control, real-time response
OEM/ODM Manufacturer, custom sizes and shapes available on request
Suggestion of new design or material, new technology and cost structure
Engineers team at your service
Flexible small orders are acceptable
One-stop supply to eliminating messy links
5Kw 10Kw 15Kw 48V 100Ah 200Ah 260Ah Lithium Rack Mounted Battery
